ICOM ID-50E
ICOM ID-50E Dual Band VHF/UHF D-STAR Digital Handheld Radio
Experience reliable digital communication with the ICOM ID-50E, a compact, feature-rich VHF/UHF dual-band handheld transceiver designed for amateur radio operators and outdoor communication enthusiasts.
Featuring advanced D-STAR digital technology, conventional FM operation, built-in GPS and USB Type-C connectivity, the ID-50E offers excellent versatility for local and worldwide amateur radio communication.
Its rugged IPX7 waterproof construction, intuitive backlit LCD and powerful 5W transmission capability make it an excellent companion for amateur radio activities and portable field operations.
Key Features
- Dual-Band VHF/UHF Operation: Supports 144–146 MHz and 430–440 MHz amateur radio transmission frequencies.
- D-STAR Digital and FM Communication: Provides digital voice and conventional analogue FM operation for flexible communication.
- 5W Transmission Power: Selectable power levels of 5W, 2.5W, 1W, 0.5W and 0.1W.
- Worldwide D-STAR Connectivity: Communicate with other amateur radio operators through compatible internet-connected D-STAR repeaters.
- Built-In GPS Receiver: Supports GPS location reporting, repeater searches, position auto-reply and GPS logging.
- USB Type-C Port: Convenient charging, PC programming and data transfer.
- Dualwatch Function: Monitor VHF/VHF, VHF/UHF or UHF/UHF frequency combinations.
- Band Scope with Waterfall Display: Identify active frequencies and monitor signal activity.
- Backlit Monochrome LCD: Clear display with user-friendly menus for convenient navigation.
- IPX7 Waterproof Protection: Designed to withstand immersion in up to 1 metre of water for 30 minutes under specified test conditions.
- microSD Card Support: Store voice recordings, GPS logs, settings and digital communication data.
- 750 mW Audio Output: Powerful built-in speaker for clear audio reception.
- 500 Memory Channels: Store frequently used frequencies for convenient access.
- VHF Airband and FM Broadcast Reception: Listen to supported aviation communication frequencies and FM broadcast stations.
Advanced D-STAR Digital Communication
The ICOM ID-50E supports D-STAR digital voice technology, enabling radio enthusiasts to communicate locally and internationally through compatible D-STAR repeater networks.
Its intuitive DR (D-STAR Repeater) function simplifies repeater selection, while Terminal Mode and Access Point Mode provide additional connectivity through compatible internet-connected computers and Android devices.
The radio also supports digital text messaging and picture sharing using compatible Icom software and accessories.
Intelligent Dualwatch and Waterfall Display
The integrated Dualwatch function allows users to monitor two frequencies across VHF and UHF bands, helping operators stay connected to multiple channels.
The Band Scope with Waterfall Display visually represents radio activity, making it easier to identify active signals and available frequencies.
Simultaneous reception of two D-STAR digital voice signals is not supported.
Built-In GPS for Smarter Communication
The integrated GPS receiver enables convenient location tracking and position reporting. Operators can locate nearby D-STAR repeaters, maintain GPS logs and share location information with compatible stations.
Rugged, Portable and Easy to Use
Designed for demanding outdoor environments, the ICOM ID-50E combines a compact lightweight body with IPX7 waterproof protection.
The bright backlit monochrome LCD improves visibility in different lighting conditions, while the powerful internal speaker delivers clear audio.
With USB Type-C charging and an approximately 8-hour operating time using the supplied BP-272 battery under specified test conditions, the ID-50E is ideal for portable amateur radio activities.
Technical Specifications
| Specification |
Details |
| Brand |
ICOM |
| Model |
ID-50E |
| Radio Type |
Digital Dual-Band Handheld Transceiver |
| Transmit Frequencies |
144–146 MHz / 430–440 MHz |
| Operating Modes |
D-STAR DV, FM, FM-N |
| Maximum RF Output |
5 Watts |
| Power Settings |
5W / 2.5W / 1W / 0.5W / 0.1W |
| Display |
Backlit Monochrome LCD |
| GPS |
Built-in |
| Waterproof Rating |
IPX7 |
| Memory Channels |
500 |
| Audio Output |
750 mW |
| Connectivity |
USB Type-C |
| Bluetooth |
Not supported |
| Memory Card |
microSD up to 32 GB |
| Battery |
BP-272 Li-ion Battery |
| Operating Time |
Approx. 8 hours under specified conditions |
| Dimensions |
58 × 111 × 27.9 mm (main unit) |
| Weight |
Approx. 300 g including battery and antenna |
Package Contents
- ICOM ID-50E Handheld Transceiver
- BP-272 Rechargeable Li-ion Battery Pack
- FA-S270C Antenna
- MB-127 Belt Clip
- Hand Strap
- USB Type-C Cable (depending on regional package)
Why Choose the ICOM ID-50E?
The ICOM ID-50E delivers an excellent balance of advanced digital features, reliable performance and portability. From everyday amateur radio communication to outdoor field operations, its D-STAR technology, built-in GPS, waterproof design and intuitive operation provide a versatile communication solution.
Explore advanced amateur radio communication with the ICOM ID-50E — compact, dependable and ready for your next adventure.
Note: Transmission requires an appropriate amateur radio licence and must comply with applicable local regulations. D-STAR network features require compatible infrastructure, software and connectivity. USB Power Delivery fast charging is not supported.
